Product Overview
Product Overview
The MSA Legend Series™ HFC Refrigerant Analyzer, powered by Neutronics technology, is a robust diagnostic tool designed for a wide array of HVAC and refrigeration applications. This analyzer is capable of measuring both vapor and liquid refrigerant to verify purity and detect the presence of other harmful refrigerants or air contaminants. It stands out as the only mobile device offering a high level of accuracy for measured refrigerants.
Key Features
- Measures vapor or liquid refrigerant.
- Confirms purity and detects harmful refrigerants or air.
- Provides highly accurate measurements for refrigerants in a mobile device.
- Offers blend analysis for measured R-400 series refrigerants.
- Allows storage of test data on an external USB drive.
- Supports remote software updates for new refrigerants.
- Supports 10 languages for global operations.
- Clean air calibration enables analysis in less than 2 minutes.
- Integrated Thermal Printer for on-site documentation.
Specifications
- Accuracy: +/-2% of single component refrigerants
- Altitude: 0 to 8,000' (2,440 m)
- Ambient Temperature: 50 to 120°F (10 to 49°C)
- Display Size: 5"
- Humidity: 0-95% RH non-condensing
- Measuring Range: 0-100%
- Power: 12 VDC @ 2A via 110/220 VAC, 50 - 60Hz Adapter
- Product Weight: Less than 10 lbs. (Approx. 9 lbs for shipping calculation)
- Sample Type: Vapor, Liquid
- Test Time: 120 seconds
- User Interface: Graphic Display, Soft Keys, Built-in Printer
- Warranty: 1 Year
Analyzed Refrigerants (displays % purity)
R-22, R-32, R-134a, R-404A, R-407C, R-410A, Hydrocarbons (HC), and Air
Identified Refrigerants (NO % purity)
R-12, R-1234yf, R-408A, R-409A, R-417A, R-421A, R-421B, R-422A, R-422B, R-422C, R-427A
Gases the Device Can Interact With
Hydrocarbons, R-12, R-1234yf, R-125 (FE-25), R-134a, R-143a, R-22, R-290 (Propane), R-32, R-404A, R-407C, R-408A, R-409A, R-410A, R-417A, R-421A, R-421B, R-422A, R-422B, R-422C, R-427A, R-600 (Butane), R-600a (Isobutane)
Approvals / Standards
CE Approved (Note: Approvals may vary by configuration, part number, and country. Users should contact customer service or check the product label for specific information.)
